Introduction and Objective: In clinical trial NCT03873259, a 2.6-mm lower pole stone was treated transcutaneously and ex vivo with 390-kHz burst wave lithotripsy (BWL) for 40 minutes and failed to break. The stone was subsequently fragmented with 650-kHz BWL after a 4-minute exposure. This study investigated how to fragment small stones and why varying the BWL frequency may more effectively fragment stones to dust.

Methods: A linear elastic theoretical model was used to calculate the stress created inside stones from shock wave lithotripsy (SWL) and different BWL frequencies mimicking the stone's size, shape, lamellar structure, and composition. To test model predictions about the impact of BWL frequency, matched pairs of stones (1–5 mm) were treated at (1) 390 kHz, (2) 830 kHz, and (3) 390 kHz followed by 830 kHz. The mass of fragments > 1 and 2 mm was measured over 10 minutes of exposure.

Results: The linear elastic model predicts that the maximum principal stress inside a stone increases to more than 5.5 times the pressure applied by the ultrasound wave as frequency is increased, regardless of the composition tested. The threshold frequency for stress amplification is proportionate to the wave speed divided by the stone diameter. Thus, smaller stones may be likely to fragment at a higher frequency, but not at a lower frequency below a limit. Unlike with SWL, this amplification in BWL occurs consistently with spherical and irregularly shaped stones. In water tank experiments, stones smaller than the threshold size broke fastest at high frequency (p = 0.0003), whereas larger stones broke equally well to submillimeter dust at high, low, or mixed frequencies.

Conclusions: For small stones and fragments, increasing frequency of BWL may produce amplified stress in the stone causing the stone to break. Using the strategies outlined here, stones of all sizes may be turned to dust efficiently with BWL.

We report stone comminution in the first 19 human subjects by burst wave lithotripsy (BWL), which is the transcutaneous application of focused, cyclic ultrasound pulses. This was a prospective multi-institutional feasibility study recruiting subjects undergoing clinical ureteroscopy (URS) for at least 1 stone ≤12 mm as measured on computerized tomography. During the planned URS, either before or after ureteroscope insertion, BWL was administered with a handheld transducer, and any stone fragmentation and tissue injury were observed. Up to 3 stones per subject were targeted, each for a maximum of 10 minutes. The primary effectiveness outcome was the volume percent comminution of the stone into fragments ≤2 mm. The primary safety outcome was the independent, blinded visual scoring of tissue injury from the URS video. Overall, median stone comminution was 90% (IQR 20, 100) of stone volume with 21 of 23 (91%) stones fragmented. Complete fragmentation (all fragments ≤2 mm) within 10 minutes of BWL occurred in 9 of 23 stones (39%). Of the 6 least comminuted stones, likely causative factors for decreased effectiveness included stones that were larger than the BWL beamwidth, smaller than the BWL wavelength or the introduction of air bubbles from the ureteroscope. Mild reddening of the papilla and hematuria emanating from the papilla were observed ureteroscopically. The first study of BWL in human subjects resulted in a median of 90% comminution of the total stone volume into fragments ≤2 mm within 10 minutes of BWL exposure with only mild tissue injury.

High-intensity focused ultrasound (HIFU) has been in clinical use for a variety of solid tumors and cancers. Accurate and reliable calibration is in a great need for clinical applications. An extracorporeal clinical HIFU system applied for the investigational device exemption (IDE) to the Food and Drug Administration (FDA) so that evaluation of its characteristics, performance, and safety was required.

The acoustic pressure and power output was characterized by a fiber optic probe and a radiation force balance, respectively, with the electrical power up to 2000 W. An in situ acoustic energy was established as the clinical protocol at the electrical power up to 500 W. Temperature elevation inside the tissue sample was measured by a thermocouple array. Generated lesion volume at different in situ acoustic energies and pathological examination of the lesions was evaluated ex vivo.

Acoustic pressure mapping showed the insignificant presence of side/grating lobes and pre- or post-focal peaks (≤–12 dB). Although distorted acoustic pressure waveform was found in the free field, the nonlinearity was reduced significantly after the beam propagating through tissue samples (i.e., the second harmonic of –11.8 dB at 500 W). Temperature elevation was <10°C at a distance of 10 mm away from a 20-mm target, which suggests the well-controlled HIFU energy deposition and no damage to the surrounding tissue. An acoustic energy in the range of 750–1250 J resulted in discrete lesions with an interval space of 5 mm between the treatment spots. Histology confirmed that the lesions represented a region of permanently damaged cells by heat fixation, without causing cell lysis by either cavitation or boiling.

Our characterization and ex vivo evaluation protocol met the IDE requirement. The in-situ acoustic energy model will be used in clinical trials to deliver almost consistent energy to the various targets.

Purpose: To test the effectiveness (Participant A) and tolerability (Participant B) of urinary stone comminution in the first in-human trial of a new technology, burst wave lithotripsy (BWL).

Materials and Methods: An investigational BWL and ultrasonic propulsion system was used to target a 7-mm kidney stone in the operating room before ureteroscopy (Participant A). The same system was used to target a 7.5 mm ureterovesical junction stone in clinic without anesthesia (Participant B).

Results: For Participant A, a ureteroscope inserted after 9 minutes of BWL observed fragmentation of the stone to < 2 mm fragments. Participant B tolerated the procedure without pain from BWL, required no anesthesia, and passed the stone on day 15.

Conclusions: The first in-human tests of BWL pulses were successful in that a renal stone was comminuted in < 10 minutes, and BWL was also tolerated by an awake subject for a distal ureteral stone.

Objective: Our goals were to validate stone comminution with an investigational burst wave lithotripsy (BWL) system in patient-relevant conditions and to evaluate the use of ultrasonic propulsion to move a stone or fragments to aid in observing the treatment endpoint.

Materials and Methods: The Propulse-1 system, used in clinical trials of ultrasonic propulsion and upgraded for BWL trials, was used to fragment 46 human stones (5–7 mm) in either a 15-mm or 4-mm diameter calix phantom in water at either 50% or 75% dissolved oxygen level. Stones were paired by size and composition, and exposed to 20-cycle, 390-kHz bursts at 6-MPa peak negative pressure (PNP) and 13-Hz pulse repetition frequency (PRF) or 7-MPa PNP and 6.5-Hz PRF. Stones were exposed in 5-minute increments and sieved, with fragments >2 mm weighed and returned for additional treatment. Effectiveness for pairs of conditions was compared statistically within a framework of survival data analysis for interval censored data. Three reviewers blinded to the experimental conditions scored ultrasound imaging videos for degree of fragmentation based on stone response to ultrasonic propulsion.

Results: Overall, 89% (41/46) and 70% (32/46) of human stones were fully comminuted within 30 and 10 minutes, respectively. Fragments remained after 30 minutes in 4% (1/28) of calcium oxalate monohydrate stones and 40% (4/10) of brushite stones. There were no statistically significant differences in comminution time between the two output settings (p = 0.44), the two dissolved oxygen levels (p = 0.65), or the two calyx diameters (p = 0.58). Inter-rater correlation on endpoint detection was substantial (Fleiss' kappa = 0.638, p < 0.0001), with individual reviewer sensitivities of 95%, 86%, and 100%.

Conclusions: Eighty-nine percent of human stones were comminuted with a clinical BWL system within 30 minutes under conditions intended to reflect conditions in vivo. The results demonstrate the advantage of using ultrasonic propulsion to disperse fragments when making a visual determination of breakage endpoint from the real-time ultrasound image.

The color Doppler ultrasound twinkling artifact has been found to improve detection of kidney stones with ultrasound; however, it appears on only ~60% of stones. Evidence from ex vivo kidney stones suggests twinkling arises from microbubbles stabilized in crevices on the stone surface. Yet it is unknown whether these bubbles are present on stones in humans. Here, we used a research ultrasound system to quantify twinkling in humans with kidney stones in a hyperbaric chamber. Eight human patients with non-obstructive kidney stones previously observed to twinkle were exposed to a maximum pressure of 4 atmospheres absolute (ATA) while breathing air, except during the 10-min pause at 1.6 ATA and while the pressure decreased to 1 ATA, during which patients breathed oxygen to minimize the risk of decompression sickness. A paired one-way t-test was used to compare the mean twinkle power at each pressure pause with baseline twinkling, with p < 0.05 considered to indicate significance. Results revealed that exposure to 3 and 4 ATA of pressure significantly reduced twinkle power by averages of 35% and 39%, respectively, in 7 patients (p = 0.04); data from the eighth patient were excluded because of corruption. This study supports the theory that microbubbles are present on kidney stones in humans.

A considerable publication record exists comparing sensitivity and specificity of radiological ultrasound (including point of care ultrasound) to computerized tomography for stone disease. However, the practical application of in-office ultrasound to support the growing number of kidney stone centers around the world represents a nuanced topic that is ripe for study and discussion. We provide a descriptive analysis of how in-office ultrasound is being used as an adjunct to clinical care based on our experience during 50 days in clinic at an institutionally affiliated, multidisciplinary kidney stone center. Clinic subjects gave consent and underwent ultrasound as part of research studies. Ultrasonograms were shared with and verified by the treating physician before the patient was discharged from care. We counted the number of times research imaging altered the care plan. Of the 60 patients enrolled the clinician used the information obtained from the studies in 20 (33%) to determine the course of clinical care that resulted in a change in treatment or process. Ultrasound has the potential to be a cost-effective and valuable tool that can provide more efficient workflow within a kidney stone center or urology clinic.

Ultrasonic propulsion is an investigative modality to noninvasively image and reposition urinary stones. Our goals were to test safety and effectiveness of new acoustic exposure conditions from a new transducer, and to use simultaneous ureteroscopic and ultrasonic observation to quantify stone repositioning.

During operation, ultrasonic propulsion was applied transcutaneously, whereas stone targets were visualized ureteroscopically. Exposures were 350 kHz frequency, ≤200 W/cm² focal intensity, and ≤3-second bursts per push. Ureteroscope and ultrasound (US) videos were recorded. Video clips with and without stone motion were randomized and scored for motion ≥3 mm by independent reviewers blinded to the exposures. Subjects were followed with telephone calls, imaging, and chart review for adverse events.

The investigative treatment was used in 18 subjects and 19 kidneys. A total of 62 stone targets were treated ranging in size from a collection of "dust" to 15 mm. Subjects received an average of 17 ñ 14 propulsion bursts (per kidney) for a total average exposure time of 40 ñ 40 seconds. Independent reviewers scored at least one stone movement ≥3 mm in 18 of 19 kidneys (95%) from the ureteroscope videos and in 15 of 19 kidneys (79%) from the US videos. This difference was probably because of motion out of the US imaging plane. Treatment repositioned stones in two cases that would have otherwise required basket repositioning. No serious adverse events were observed with the device or procedure.

Ultrasonic propulsion was shown to be safe, and it effectively repositioned stones in 95% of kidneys despite positioning and access restrictions caused by working in an operating room on anesthetized subjects.

Proceedings, 176th Meeting of the Acoustical Society of America, 5-9 November 2018, Victoria, BC, Canada.

Non-invasive kidney stone treatments such as shock wave lithotripsy (SWL) and burst wave lithotripsy (BWL) rely on the delivery of pressure waves through tissue to the stone. In both SWL and BWL, the potential to hinder comminution by exciting cavitation proximal to the stone has been reported. To elucidate how different stones alter prefocal cavitation in BWL, different natural and synthetic stones were treated in vitro using a therapy transducer operating at 350 kHz (peak negative pressure 7 MPa, pulse length 20 cycles, pulse repetition frequency 10 Hz). Stones were held in a confined volume of water designed to mimic the geometry of a kidney calyx, with the water filtered and degassed to maintain conditions for which the cavitation threshold (in the absence of a stone) matches that from in vivo observations. Stone targeting and cavitation monitoring were performed via ultrasound imaging using a diagnostic probe aligned coaxially with the therapy transducer. Quantitative differences in the extent and location of cavitation activity were observed for different stone types — e.g., stones (natural and synthetic) that are known to be porous produced larger prefocal cavitation clouds. Ongoing work will focus on correlation of such cavitation metrics with stone fragmentation.

176th Meeting of the Acoustical Society of America 5-9 November 2018, Victoria, BC, Canada.

Our goal is an office-based, handheld ultrasound system to target, detach, break, and/or expel stones and stone fragments from the urinary collecting system to facilitate natural clearance. Repositioning of stones in humans (maximum 2.5 MPa, and 3-second bursts) and breaking of stones in a porcine model (maximum 50 cycles, 20 Hz repetition, 30 minutes, and 7 MPa peak negative pressure) have been demonstrated using the same 350-kHz probe. Repositioning in humans was conducted during surgery with a ureteroscope in the kidney to film stone movement. Independent video review confirmed stone movements (≥ 3 mm) in 15 of 16 kidneys (94%). No serious or unanticipated adverse events were reported. Experiments of burst wave lithotripsy (BWL) effectiveness on breaking human stones implanted in the porcine bladder and kidney demonstrated fragmentation of 7 of 7 stones on post mortem dissection. A 1-week survival study with the BWL exposures and 10 specific pathogen-free pigs, showed all findings were within normal limits on clinical pathology, hematology, and urinalysis. These results demonstrate that repositioning of stones with ultrasonic propulsion and breaking of stones with BWL are safe and effective.

Introduction: Studies suggest that the width of the acoustic shadow on ultrasound (US) more accurately reflects true stone size than the stone width in US images. We evaluated the need for training in the adoption of the acoustic shadow sizing technique by clinical providers.

Methods: Providers without shadow sizing experience were recruited and assigned in a stratified, alternating manner to receive a training tutorial ("trained") or no intervention ("control"). Each conducted a baseline assessment of 24 clinical US images; where present, shadow width was measured using custom calipers. The trained group subsequently completed a standardized training module on shadow sizing. All subjects repeated measurements after ~1 week. Group demographics were compared using Fisher's exact test. Measurements were compared to clinically reported stone sizes on corresponding CT and US using mixed-effects models. One millimeter concordance between shadow and CT size was compared using a generalized linear mixed-effects model.

Results: Twenty-six subjects were included. There was no significant difference between groups in demographics, clinical role, or US experience. Mean reported CT and US stone sizes were 6.8 ±â€‰4.0 mm and 10.3 ±â€‰4.1 mm, respectively. At baseline, there was no difference in shadow size measurements between groups (p = 0.18), and shadow size was no more accurate than US stone size (p = 0.28 trained; p = 0.81 control), compared to CT. After training, overestimation bias of shadow size in the trained group decreased to 1.6 ±â€‰0.5 mm (p < 0.01), relative to CT. This was not significantly associated with clinical rank, US experience, or stone-measuring experience. One millimeter concordance with CT size significantly increased from 23% to 35% of stones after training (p = 0.01). No significant improvement occurred in the control group.

Conclusion: Acoustic shadow sizing was readily adopted by inexperienced providers, but was not more accurate than reported US stone sizes without training. Education on shadow sizing may be warranted before clinical adoption.

Purpose

Posterior acoustic shadow width has been proposed as a more accurate measure of kidney stone size compared to direct measurement of stone width on ultrasound (US). Published data in humans to date have been based on a research using US system. Herein, we compared these two measurements in clinical US images.

Methods

Thirty patient image sets where computed tomography (CT) and US images were captured less than 1 day apart were retrospectively reviewed. Five blinded reviewers independently assessed the largest stone in each image set for shadow presence and size. Shadow size was compared to US and CT stone sizes.

Results

Eighty percent of included stones demonstrated an acoustic shadow; 83% of stones without a shadow were ≤5 mm on CT. Average stone size was 6.5 ± 4.0 mm on CT, 10.3 ± 4.1 mm on US, and 7.5 ± 4.2 mm by shadow width. On average, US overestimated stone size by 3.8 ± 2.4 mm based on stone width (p < 0.001) and 1.0 ± 1.4 mm based on shadow width (p < 0.0098). Shadow measurements decreased misclassification of stones by 25% among three clinically relevant size categories (≤ 5, 5.1–10, > 10 mm), and by 50% for stones ≤ 5 mm.

Conclusions

US overestimates stone size compared to CT. Retrospective measurement of the acoustic shadow from the same clinical US images is a more accurate reflection of true stone size than direct stone measurement. Most stones without a posterior shadow are ≤ 5 mm.

Purpose

Burst wave lithotripsy (BWL) is a new technology in development to fragment urinary stones. Ultrasonic propulsion (UP) is a separate technology under investigation for displacing stones. We measure the effect of propulsion pulses on stone fragmentation from BWL.

Materials and Methods

Two artificial stone models (crystalline calcite, BegoStone plaster) and human calcium oxalate monohydrate (COM) stones measuring 5 to 8 mm were subjected to ultrasound exposures in a polyvinyl chloride tissue phantom within a water bath. Stones were exposed to BWL with and without propulsion pulses interleaved for set time intervals depending on stone type. Fragmentation was measured as a fraction of the initial stone mass fragmented to pieces smaller than 2 mm.

Results

BegoStone model comminution improved from 6% to 35% (p < 0.001) between BWL and BWL with interleaved propulsion in a 10-minute exposure. Propulsion alone did not fragment stones, whereas addition of propulsion after BWL slightly improved BegoStone model comminution from 6% to 11% (p < 0.001). BegoStone model fragmentation increased with rate of propulsion pulses. Calcite stone fragmentation improved from 24% to 39% in 5 minutes (p = 0.047) and COM stones improved from 17% to 36% (p = 0.01) with interleaved propulsion.

Conclusions

BWL with UP improved stone fragmentation compared with BWL alone in vitro. The improvement was greatest when propulsion pulses are interleaved with BWL treatment and when propulsion pulses are applied at a higher rate. Thus, UP may be a useful adjunct to enhance fragmentation in lithotripsy in vivo.

Kidney stones can exhibit a twinkling artifact under color-flow Doppler ultrasound. There has been much work that suggests the mechanism for this artifact is micron sized bubbles trapped in the cracks of the stone cavitating from the incident Doppler pulses. We hypothesize that the signal-to-clutter ratio (SCR) of stone-to-background in Doppler mode increases with the ultrasound mechanical index (MI), a metric of the likelihood of cavitation, and that a minimum MI is needed for visibility under Doppler.

Our results show the contrast ratio of the twinkling artifact on a kidney stone to background noise increases with the MI. This suggests that adjusting the system settings to increase the MI on the stone, such as lowering the frequency and increasing the amplitude, will improve stone contrast and the ability to detect a kidney stone. Additionally, ultrasound manufacturers can potentially implement a stone-specific imaging preset for Doppler that maximizes the MI of the output while remaining within the regulated safety limits.

Objective

To evaluate in more detail the effectiveness of a new designed more efficient ultrasonic propulsion for large stones and specific stone compositions in a tissue phantom model. In the first clinical trial of noninvasive ultrasonic propulsion, urinary stones of unknown compositions and sizes up to 10 mm were successfully repositioned.

Materials and Methods

The study included 8- to 12-mm stones of 4 different primary compositions (calcium oxalate monohydrate, ammonium acid urate, calcium phosphate, and struvite) and a renal calyx phantom consisting of a 12 mm x 30 mm well in a 10-cm block of tissue-mimicking material. Primary outcome was the number of times a stone was expelled over 10 attempts, with ultrasonic propulsion burst duration varying from 0.5 seconds to 5 seconds.

Results

Overall success rate at expelling stones was 95%. All calcium oxalate monohydrate and ammonium acid urate stones were expelled 100% of the time. The largest stone (12 mm) became lodged within the 12-mm phantom calyx 25% of the time regardless of the burst duration. With the 0.5-second burst, there was insufficient energy to expel the heaviest stone (0.88 g), but there was sufficient energy at the longer burst durations.

Conclusion

With a single burst, ultrasonic propulsion successfully moved most stones at least 3 cm and, regardless of size or composition, expelled them from the calyx. Ultrasonic propulsion is limited to the stones smaller than the calyceal space, and for each burst duration, related to maximum stone mass.

A noninvasive ultrasound (US) system to facilitate the passage of small kidney stones has been developed. The device incorporates a software-based US platform programmed with brightness mode and Doppler for visualizing stones, plus long duration focused pulses for repositioning stones using the same transducer. This paper characterizes the acoustic outputs of the ultrasonic propulsion device. Though the application and outputs are unique, measurements were performed based on the regulatory standards for both diagnostic US and extracorporeal lithotripters. The extended length of the pulse, time varying pressure output over the pulse, the use of focused targeting, and the need to regulate the output at shallow depths, however, required modifications to the traditional acoustic measurement methods. Output parameters included spatial-peak intensities, mechanical index (MI), thermal index, pulse energy, focal geometry, and target accuracy. The imaging and Doppler operating modes of the system meet the Food and Drug Administration acoustic power and intensity limits for diagnostic US device. Push mode operates at a maximum MI of 2.2, which is above the limit of 1.9 for diagnostic US, but well below any lithotripsy device and an ISPTA of 548 mW/cm², which is below the 720-mW/cm² limit for diagnostic US.

The use of shock waves for enhancing thermal effects and mechanically ablating tissue is gaining increased attention in high intensity focused ultrasound (HIFU) applications such as tumor treatment, drug delivery, noninvasive biopsy, and immunotherapy. For abdominal targets, the presence of ribs and inhomogeneous adipose tissue can affect shock formation through aberration, absorption, and diffraction. The goal of this study was to design and validate a phantom for investigating the impact of different tissue structures on shock formation in situ. A transducer with driving electronics was developed to operate at 1.2 MHz with the ability to deliver either short pulses at high powers (up to 5 kW electric power) or continuous output at moderate powers (up to 700 W). Fat and muscle layers were represented by phantoms made from polyvinyl alcohol. Ribs were 3D-printed from a photopolymer material based on 3D CT scan images. Representative targeted tissue was comprised of optically transparent alginate or polyacrylamide gels. The system was characterized by hydrophone measurements free-field in water and in the presence of a body wall or rib phantoms. Shocked waveforms with peak positive/negative pressures of +100 / –20 MPa were measured at the focus in a free field at 1 kW electric source power. When ribs were present, shocks formed at about 50% amplitude at the same power, and higher pressures were measured with ribs positioned closer to the transducer. A uniform body wall structure attenuated shock amplitudes by a smaller amount than non-uniform, and the measurements were insensitive to the axial position of the phantom. Signal magnitude loss at the focus for both the rib phantoms and abdominal wall tissue were consistent with results from real tissues. In addition, boiling histotripsy lesions were generated and visualized in the target gels. The results demonstrate that the presence of ribs and absorptive tissue-mimicking layers do not prevent shock formation at the focus. With real-time lesion visualization, the phantom is suitable for adaptation as a training tool.

Hyperbaric pressures of 3–100 atmospheres absolute (ATA) have been shown to reduce the color Doppler ultrasound twinkling artifact on ex vivo human kidney stones, leading to the hypothesis that surface crevice microbubbles cause twinkling. Similarly supportive for the crevice bubble hypothesis is the suppression of kidney stone twinkling in animals breathing elevated levels of carbon dioxide. However, it is unclear whether stable microbubbles can exist on the surface of kidney stones in the human body. For the first time, we investigate the effect of hyperbaric pressure on in situ human kidney stones to determine whether stable microbubbles exist as measured by the color Doppler ultrasound twinkling artifact.

In the first-in-human trial of ultrasonic propulsion, subjects passed collections of residual stone fragments after repositioning with a C5-2 probe. Here, effectiveness and safety in moving multiple fragments is compared between the C5-2 and a custom SC-50 probe that produces a longer beam and burst duration.

Purpose: Greater visual contrast between calculi and tissue would improve ultrasound (US) imaging of urolithiasis and potentially expand clinical use. The color Doppler twinkling artifact has been suggested to provide enhanced contrast of stones compared with brightness mode (B-mode) imaging, but results are variable. This work provides the first quantitative measure of stone contrast in humans for B-mode and color Doppler mode, forming the basis to improve US for the detection of stones.

Materials and Methods: Using a research ultrasound system, B-mode imaging was tuned for detecting stones by applying a single transmit angle and reduced signal compression. Stone twinkling with color Doppler was tuned by using low-frequency transmit pulses, longer pulse durations, and a high-pulse repetition frequency. Data were captured from 32 subjects, with 297 B-mode and Doppler images analyzed from 21 subjects exhibiting twinkling signals. The signal to clutter ratio (i.e., stone to background tissue) (SCR) was used to compare the contrast of a stone on B-mode with color Doppler, and the contrast between stone twinkling and blood-flow signals within the kidney.

Results: The stone was the brightest object in only 54% of B-mode images and 100% of Doppler images containing stone twinkling. On average, stones were isoechoic with the tissue clutter on B-mode (SCR = 0 dB). Stone twinkling averaged 37 times greater contrast than B-mode (16 dB, p < 0.0001) and 3.5 times greater contrast than blood-flow signals (5.5 dB, p = 0.088).

Conclusions: This study provides the first quantitative measure of US stone to tissue contrast in humans. Stone twinkling contrast is significantly greater than the contrast of a stone on B-mode. There was also a trend of stone twinkling signals having greater contrast than blood-flow signals in the kidney. Dedicated optimization of B-mode and color Doppler stone imaging could improve US detection of stones.

Therapeutic ultrasound can drive bubble activity that damages soft tissues. To study the potential mechanisms of such injury, transparent agar tissue-mimicking phantoms were subjected to multiple pressure wave bursts of the kind being considered specifically for burst wave lithotripsy. A high-speed camera recorded bubble activity during each pulse. Various agar concentrations were used to alter the phantom's mechanical properties, especially its stiffness, which was varied by a factor of 3.5. However, the maximum observed bubble radius was insensitive to stiffness. During 1000 wave bursts of a candidate burst wave lithotripsy treatment, bubbles appeared continuously in a region that expanded slowly, primarily toward the transducer. Denser bubble clouds are formed at higher pulse repetition frequency. The specific observations are used to inform the incorporation of damage mechanisms into cavitation models for soft materials.

Purpose: In the first-in-human trial of ultrasonic propulsion, subjects passed collections of residual stone fragments repositioned with a C5-2 probe. Here, effectiveness and safety in moving multiple fragments are compared between the C5-2 and a custom (SC-50) probe that produces a longer focal beam and burst duration.

Materials and Methods: Effectiveness was quantified by the number of stones expelled from a calyx phantom consisting of a 30-mm deep, water-filled well in a block of tissue mimicking material. Each probe was positioned below the phantom to move stones against gravity. Single propulsion bursts of 50 ms or 3 s duration were applied to three separate targets: 10 fragments of 2 different sizes (1–2 and 2–3 mm) and a single 4 x 7 mm human stone. Safety studies consisted of porcine kidneys exposed to an extreme dose of 10-minute burst duration, including a 7-day survival study and acute studies with surgically implanted stones.

Results: Although successful in the clinical trial, the shorter focal beam and maximum 50 ms burst duration of the C5-2 probe moved stones, but did not expel any stones from the phantom's 30-mm deep calyx. The results were similar with the SC-50 probe under the same 50 ms burst duration. Longer (3 s) bursts available with the SC-50 probe expelled all stones at both 4.5 and 9.5 cm "skin-to-stone" depths with lower probe heating compared to the C5-2. No abnormal behavior, urine chemistry, serum chemistry, or histological findings were observed within the kidney or surrounding tissues for the 10 min burst duration used in the animal studies.

Conclusions: A longer focal beam and burst duration improved expulsion of a stone and multiple stone fragments from a phantom over a broad range of clinically relevant penetration depths and did not cause kidney injury in animal studies.

Bone demineralization, dehydration, and stasis put astronauts at an increased risk of forming kidney stones in space. The incidence of kidney stones and the potential for a mission-critical event are expected to rise as expeditions become longer and immediate transport to Earth becomes more problematic. At the University of Washington, we are developing an ultrasound-based stone management system to detect stones with S-mode^TM ultrasound imaging, break stones with burst wave lithotripsy (BWL^TM), and reposition stones with ultrasonic propulsion (UP^TM) on Earth and in space. This review discusses the development and current state of these technologies, as well as integration on the flexible ultrasound system sponsored by NASA and the National Space Biomedical Research Institute.

Ultrasonic propulsion is a new technology using focused ultrasound energy applied transcutaneously to reposition kidney stones. We report the findings from the first human investigational trial of ultrasonic propulsion toward the applications of expelling small stones and dislodging large obstructing stones.

Subjects underwent ultrasonic propulsion either awake without sedation in clinic or during ureteroscopy while anesthetized. Ultrasound imaging and a pain questionnaire were completed before, during, and after propulsion. The primary outcome was to reposition stones in the collecting system. Secondary outcomes included safety, controllable movement of stones, and movement of stones < 5 mm and ≥ 5 mm. Adverse events were assessed weekly for 3 weeks.

Kidney stones were repositioned in 14 of 15 subjects. Of the 43 targets, 28 (65%) showed some level of movement while 13 (30%) were displaced > 3 mm to a new location. Discomfort during the procedure was rare, mild, brief, and self-limited. Stones were moved in a controlled direction with over 30 fragments being passed by 4 of 6 subjects who previously had a lithotripsy procedure. The largest stone moved was 10 mm. One patient experienced pain relief during treatment of a large stone at the UPJ. In 4 subjects a seemingly large stone was determined to be a cluster of small passable stones once moved.

Ultrasonic propulsion was able to successfully reposition stones and facilitate passage of fragments in humans with no adverse events associated with the investigational procedure.

Ultrasound is known to overestimate kidney stone size. We explored measuring the acoustic shadow behind kidney stones combined with different ultrasound imaging modalities to improve stone sizing accuracy. A total of 45 calcium oxalate monohydrate stones were imaged in vitro at 3 different depths with the 3 different ultrasound imaging modalities of conventional ray line, spatial compound and harmonic imaging. The width of the stone and the width of the acoustic shadow were measured by 4 operators blinded to the true size of the stone.

Shadow width was a more accurate measure of true stone size than a direct measurement of the stone in the ultrasound image (p <0.0001). The ultrasound imaging modality also impacted the measurement accuracy. All methods performed similarly for shadow size while harmonic imaging was the most accurate stone size modality. Overall 78% of the shadow sizes were accurate to within 1 mm, which is similar to the resolution obtained with clinical computerized tomography.

In animal models, pretreatment with low-energy shock waves and a pause decreased renal injury from shockwave lithotripsy (SWL). This is associated with an increase in perioperative renal resistive index (RI). A perioperative rise is not seen without the protective protocol, which suggests that renal vasoconstriction during SWL plays a role in protecting the kidney from injury. The purpose of our study was to investigate whether there is an increase in renal RI during SWL in humans.

Subjects were prospectively recruited from two hospitals. All subjects received an initial 250 shocks at low setting, followed by a 2-minute pause. Treatment power was then increased. Measurements of the renal RI were taken before start of procedure, at 250, after 750, after 1500 shocks, and at the end of the procedure. A linear mixed-effects model was used to compare RIs at the different time points.

Fifteen patients were enrolled. Average treatment time was 46±8 minutes. Average RI at pretreatment, after 250, after 750, after 1500 shocks, and post-treatment was 0.67±0.06, 0.69±0.08, 0.71±0.07, 0.73±0.07, and 0.74±0.06, respectively. In adjusted analyses, RI was significantly increased after 750 shocks compared with pretreatment (p=0.05).

Renal RI increases early during SWL in humans with the protective protocol. Monitoring for a rise in RI during SWL is feasible and may provide real-time feedback as to when the kidney is protected.

Transcutaneous focused ultrasound (US) is used to propel kidney stones using acoustic radiation force. It is important to estimate the level of heating generated at the stone/tissue interface for safety assessment. An in-vitro experiment is conducted to measure the temperature rise in a tissue-mimicking phantom with an embedded artificial stone and subjected to a focused beam from an imaging US array. A novel optical-imaging-based thermometry method is described using an optically clear tissue phantom. Measurements are compared to the output from a fine wire thermocouple placed on the stone surface. The optical method has good sensitivity, and it does not suffer from artificial viscous heating typically observed with invasive probes and thermocouples.

Ultrasound (US) overestimates stone size when compared with CT. The purpose of this work was to evaluate the overestimation of stone size with US in an in vitro water bath model and investigate methods to reduce overestimation.

Ten human stones (3–12 mm) were measured using B-mode (brightness mode) US by a sonographer blinded to the true stone size. Images were captured and compared using both a commercial US machine and software-based research US device. Image gain was adjusted between moderate and high stone intensities, and the transducer-to-stone depth was varied from 6 to 10 cm. A computerized stone-sizing program was developed to outline the stone width based on a grayscale intensity threshold.

Overestimation with the commercial device increased with both gain and depth. Average overestimation at moderate and high gain was 1.9±0.8 and 2.1±0.9 mm, respectively (p=0.6). Overestimation increased an average of 22% with an every 2-cm increase in depth (p=0.02). Overestimation using the research device was 1.5±0.9 mm and did not vary with depth (p=0.28). Overestimation could be reduced to 0.02±1.1 mm (p<0.001) with the computerized stone-sizing program. However, a standardized threshold consistent across depth, system, or system settings could not be resolved.

Stone size is consistently overestimated with US. Overestimation increased with increasing depth and gain using the commercial machine. Overestimation was reduced and did not vary with depth, using the software-based US device. The computerized stone-sizing program shows the potential to reduce overestimation by implementing a grayscale intensity threshold for defining the stone size. More work is needed to standardize the approach, but if successful, such an approach could significantly improve stone-sizing accuracy and lead to automation of stone sizing.

Objective
To provide an update on a research device to ultrasonically reposition kidney stones transcutaneously. This article reports preclinical safety and effectiveness studies, survival data, modifications of the system, and testing in a stone-forming porcine model. These data formed the basis for regulatory approval to test the device in humans.

Materials and Methods
The ultrasound burst was shortened to 50 ms from previous investigations with 1-s bursts. Focused ultrasound was used to expel 2- to 5-mm calcium oxalate monohydrate stones placed ureteroscopically in 5 pigs. Additionally, de novo stones were imaged and repositioned in a stone-forming porcine model. Acute safety studies were performed targeting 2 kidneys (6 sites) and 3 pancreases (8 sites). Survival studies followed 10 animals for 1 week after simulated treatment. Serum and urine analyses were performed, and tissues were evaluated histologically.

Results
All ureteroscopically implanted stones (6/6) were repositioned out of the kidney in 14 ± 8 minutes with 13 ± 6 bursts. On average, 3 bursts moved a stone more than 4 mm and collectively accounted for the majority of relocation. Stones (3 mm) were detected and repositioned in the 200-kg stone-forming model. No injury was detected in the acute or survival studies.

Conclusion
Ultrasonic propulsion is safe and effective in the porcine model. Stones were expelled from the kidney. De novo stones formed in a large porcine model were repositioned. No adverse effects were identified with the acute studies directly targeting kidney or pancreatic tissue or during the survival studies indicating no evidence of delayed tissue injury.

The global prevalence and incidence of renal calculi is reported to be increasing. Of the patients that undergo surgical intervention, nearly half experience symptomatic complications associated with stone fragments that are not passed and require follow-up surgical intervention. In a clinical simulation using a clinical prototype, ultrasonic propulsion was proven effective at repositioning kidney stones in pigs. The use of ultrasound to reposition smaller stones or stone fragments to a location that facilitates spontaneous clearance could therefore improve stone-free rates. The goal of this study was to determine an injury threshold under which stones could be safely repositioned.

Kidneys of 28 domestic swine were treated with exposures that ranged in duty cycle from 0%–100% and spatial peak pulse average intensities up to 30 kW/cm² for a total duration of 10 min. The kidneys were processed for morphological analysis and evaluated for injury by experts blinded to the exposure conditions.

At a duty cycle of 3.3%, a spatial peak intensity threshold of 16,620 W/cm² was needed before a statistically significant portion of the samples showed injury. This is nearly seven times the 2,400-W/cm² maximum output of the clinical prototype used to move the stones effectively in pigs.

The data obtained from this study show that exposure of kidneys to ultrasonic propulsion for displacing renal calculi is well below the threshold for tissue injury.

Purpose: Ultrasonic propulsion to reposition urinary tract calculi requires knowledge about ultrasound image capture, device manipulation, and interpretation. The purpose of this study was to validate a cognitive and technical skills curriculum to teach urologists ultrasonic propulsion to reposition kidney stones in tissue phantoms.

Materials and Methods: Ten board-certified urologists recruited from a single institution underwent a didactic session on renal ultrasound imaging. Subjects completed technical skills modules in tissue phantoms, including kidney imaging, pushing a stone through a translucent maze, and repositioning a lower pole calyceal stone. Objective cognitive and technical performance metrics were recorded. Subjects completed a questionnaire to ascertain face and content validity on a five-point Likert scale.

Results: Eight urologists (80%) had never attended a previous ultrasound course, and nine (90%) performed renal ultrasounds less frequently than every 6 months. Mean cognitive skills scores improved from 55% to 91% (p<0.0001) on pre- and post-didactic tests. In the kidney phantom, 10 subjects (100%) repositioned the lower pole calyceal stone to at least the lower pole infundibulum, while 9 (90%) successfully repositioned the stone to the renal pelvis. A mean±SD (15.7±13.3) pushes were required to complete the task over an average of 4.6±2.2 minutes. Urologists rated the curriculum's effectiveness and realism as a training tool at a mean score of 4.6/5.0 and 4.1/5.0, respectively.

Conclusions: The curriculum for ultrasonic propulsion is effective and useful for training urologists with limited ultrasound proficiency in stone repositioning technique. Further studies in animate and human models will be required to assess predictive validity.

A method of non-contact mapping of venous oxygen saturation (SvO₂) is presented. A CCD camera is used to image skin tissue illuminated alternately by a red (660 nm) and an infrared (800 nm) LED light source. Low cuff pressures of 30–40 mmHg are applied to induce a venous blood volume change with negligible change in the arterial blood volume. A hybrid model combining the Beer–Lambert law and the light diffusion model is developed and used to convert the change in the light intensity to the change in skin tissue absorption coefficient. A simulation study incorporating the full light diffusion model is used to verify the hybrid model and to correct a calculation bias. SvO₂ in the fingers, palm, and forearm for five volunteers are presented and compared with results in the published literature. Two-dimensional maps of venous oxygen saturation are given for the three anatomical regions.

Ultrasound imaging has tissue and blood imaging modes. This report describes development of a kidney stone imaging mode. Two plane pulses generate a B-mode image. Overlaid in color are regions of high decorrelation between the pulses. Our previous data [UMB, 39, 1026-1038 (2013)] indicate the pulses excite bubbles on the stone surface, which causes the decorrelation. As such this mode automatically identifies stones in the image while scanning at a high frame rate. Further in a control box placed on the stone, highly focused beams are scanned across the stone and a harmonic B-mode image is produced to sharpen the lateral resolution. This mode is used to refine the size and shape of the stone. The first mode is used to aid visualization of stones. Our team is also using it to target and track stones that move with respiration during shock wave lithotripsy (SWL) and as an indicator of stone susceptibility to SWL since surface bubbles contribute to comminution. Improved stone sizing by the second mode aids treatment planning, and resolution of surface roughness is another indicator of stone fragility.

The use of projection methods is increasingly accepted as a standard way of characterizing the 3D fields generated by medical ultrasound sources. When combined with hydrophone measurements of pressure amplitude and phase over a surface transverse to the wave propagation, numerical projection can be used to reconstruct 3D fields that account for operational details and imperfections of the source. Here, we use holography measurements to characterize the fields generated by two array transducers with different geometries and modes of operation. First, a seven-element, high-power therapy transducer is characterized in the continuous-wave regime using holography measurements and nonlinear forward-projection calculations. Second, a C5-2 imaging probe (Philips Healthcare) with 128 elements is characterized in the transient regime using holography measurements and linear projection calculations. Results from the numerical projections for both sources are compared with independent hydrophone measurements of select waveforms, including shocked focal waveforms for the therapy transducer. Accurate 3D field representations have been confirmed, though a notable sensitivity to hydrophone calibrations is revealed. Uncertainties associated with this approach are discussed toward the development of holography measurements combined with numerical projections as a standard metrological tool.

Purpose
Focused ultrasound has the potential to expel small stones or residual stone fragments from the kidney, or move obstructing stones to a non-obstructing location. The purpose of this study was to evaluate the efficacy and safety of ultrasonic propulsion in a live porcine model.

Material and Methods
Calcium oxalate monohydrate kidney stones and laboratory model stones (2–8 mm) were ureteroscopically implanted within the renal pelvicalyceal system of 12 kidneys in eight domestic swine. Transcutaneous ultrasonic propulsion was performed using a Philips HDI C5-2 imaging transducer and Verasonics diagnostic ultrasound platform. Successful stone relocation was defined as stone movement from the calyx to the renal pelvis, ureteropelvic junction (UPJ) or proximal ureter. Efficacy and procedure time were determined. Three blinded experts evaluated for histologic injury to the kidney in control, sham, and treatment arms.

Results
All stones were observed to move during treatment, and 65% (17/26) were relocated successfully to the renal pelvis (3), UPJ (2), or ureter (12). Average successful procedure time was 14±8 min and required 23±16 ultrasound bursts of ~1 sec duration. There was no evidence of gross or histologic injury to the renal parenchyma in kidneys exposed to 20 bursts (1 sec duration, 33 sec intervals) at the same output (2400 W/cm²) used to push stones.

Conclusions
Non-invasive transcutaneous ultrasonic propulsion is a safe, effective, and time-efficient means to relocate calyceal stones to the renal pelvis, UPJ, or ureter. This technology holds promise as a useful adjunct to the surgical management of renal calculi.

The temperature dependence of an agar/gelatin phantom was evaluated. The purpose was to predict the material property response to high-intensity focused ultrasound (HIFU) for developing ultrasound guided dosing and targeting feedback. Changes in attenuation, sound speed, shear modulus and thermal properties with temperature were examined from 20°C to 70°C for 3 weeks post-manufacture. The attenuation decreased with temperature by a power factor of 0.15. Thermal conductivity, diffusivity and specific heat all increased linearly with temperature for a total change of approximately 16%, 10% and 6%, respectively. Sound speed had a parabolic dependence on temperature similar to that of water. Initially, the shear modulus irreversibly declined with even a slight increase in temperature. Over time, the gel maintained its room temperature shear modulus with moderate heating. A stable phantom was achieved within 2 weeks post-manufacture that possessed quasi-reversible material properties up to nearly 55°C.

"Twinkling" is a widely reported ultrasound artifact whereby kidney stones and other similar calcified, strongly reflective objects appear as turbulent, flowing blood in color and power Doppler. The twinkling artifact has been shown to improve kidney stone detection over B-mode imaging alone, but its use has several limitations. Principally, twinkling can be confused with blood flow, potentially leading to an incorrect diagnosis. Here a new method is reported for explicitly suppressing the display of color from blood flow to enhance and/or isolate the twinkle signal. The method applies an autoregressive model to standard Doppler pulses in order to differentiate tissue, blood flow, and twinkling. The algorithm was implemented on a software-based, open architecture ultrasound system and tested by a sonographer on phantoms and on stones implanted in a live porcine kidney. Stones of 3-10 mm were detected reproducibly while suppressing blood flow in the image. In conclusion, a new algorithm designed to specifically detect stones has been tested and has potential clinical utility especially as efforts are made to reduce radiation exposure on diagnosis and monitoring.

Phantoms used for high intensity focused ultrasound (HIFU) applications require rigorous evaluation of material properties since, locally, the material experiences extreme changes in temperature and stresses with the HIFU treatment. Here we present the testing of an agar-gelatin phantom intended for both acoustic radiation force imaging (ARFI) and HIFU applications. The phantom shear modulus, speed of sound, attenuation, and thermal properties were all evaluated over the range of room temperature to 80C. With the exception of the thermal properties, all measurements were taken during both heating and cool down. Cavitation threshold and melting point were also tested. The change in material sound speed and thermal properties with temperature were quasireversible and similar to that of water. Material attenuation showed a slight decrease with temperature, but appeared to also be reversible. Shear modulus decreased significantly with temperature, going to near zero. The response was not reversible, returning to only approximately one-third of the starting value. These results demonstrate the complex material response that can occur with HIFU treatment. The results also raise the question of how well the test procedures, and thus results, properly reflect the true HIFU conditions.

Tissue Pulsatility Imaging (TPI) is an ultrasonic technique that is being developed at the University of Washington to measure tissue displacement or strain due to blood flow over the cardiac and respiratory cycles. This technique is based in principle on plethysmography, an older non-ultrasound technology for measuring expansion of a whole limb or body part due to perfusion. TPI adapts tissue Doppler signal processing methods to measure the "plethysmographic" signal from hundreds or thousands of sample volumes in an ultrasound image plane. This paper presents a feasibility study to determine if TPI can be used to assess cerebral vasoreactivity. Ultrasound data were collected transcranially through the temporal acoustic window from four subjects before, during, and after voluntary hyperventilation. In each subject, decreases in tissue pulsatility during hyperventilation were observed that were statistically correlated with the subject's end-tidal CO₂ measurements.

Functional tissue pulsatility imaging is a new ultrasonic technique being developed to map brain function by measuring changes in tissue pulsatility as a result of changes in blood flow with neuronal activation. The technique is based in principle on plethysmography, an older, nonultrasound technology for measuring expansion of a whole limb or body part as a result of perfusion. Perfused tissue expands by a fraction of a percent early in each cardiac cycle when arterial inflow exceeds venous outflow, and it relaxes later in the cardiac cycle when venous drainage dominates. Tissue pulsatility imaging (TPI) uses tissue Doppler signal processing methods to measure this pulsatile "plethysmographic" signal from hundreds or thousands of sample volumes in an ultrasound image plane. A feasibility study was conducted to determine if TPI could be used to detect regional brain activation during a visual contrast-reversing checkerboard block paradigm study. During a study, ultrasound data were collected transcranially from the occipital lobe as a subject viewed alternating blocks of a reversing checkerboard (stimulus condition) and a static, gray screen (control condition). Multivariate analysis of variance was used to identify sample volumes with significantly different pulsatility waveforms during the control and stimulus blocks. In 7 of 14 studies, consistent regions of activation were detected from tissue around the major vessels perfusing the visual cortex.

It is known that bruits often can be heard downstream from stenoses. They are thought to be produced by disturbed blood flow and vessel wall vibrations. Our understanding of bruits has been limited, though, to analysis of sounds heard at the level of the skin. For direct measurements from the stenosis site, we developed an ultrasonic pulse-echo multigate system using quadrature phase demodulation. The system simultaneously measures tissue displacements and blood velocities at multiple depths. This paper presents a case study of a severe stenosis in a human infrainguinal vein bypass graft. During systole, nearly sinusoidal vessel wall vibrations were detected. Solid tissue vibration amplitudes measured up to 2 microm, with temporal durations of 100 ms and frequencies of roughly 145 Hz and its harmonics. Cross-axial oscillations were also found in the lumen that correlate with the wall vibrations, suggesting coupling between wall vibration and blood velocity oscillation.
